Description:
- Ultra-Light Hollow Core Carbon Frame
- Toolshed™ In-Frame Storage
- New Dual Cable Port Design
- Large Water Bottle Clearance on all sizes
- Fits riders between 4’10” and 6’5”+ with X-Small to X-Large size offerings
- Flip Chip for on-trail geometry customization
- MX Wheel Compatible
- Pivot Tool Dock system compatible with mounts under the top tube and integrated into the underside of the frame
- Hassle free full internal routing with Pivot cable port system
- UDH Derailleur Hanger
Specs:
| KIT | Ride GX Eagle Transmission |
| WHEEL SIZE | 29" |
| FRAME | Trailcat SL |
| WHEEL MATERIAL | Alloy |
| REAR SHOCK | Fox Performance Float |
| FORK | Fox Performance 34 29", GRIP - 140mm |
| HEADSET | Pivot Precision Sealed Cartridge |
| REAR DER | Sram GX Eagle Transmission 12-Speed |
| CASSETTE | Sram GX 1275 Eagle Transmission 10-52t |
| SHIFTER | Sram AXS Pod Controller |
| BRAKES | Sram DB8 Stealth 4-piston |
| CRANKSET | Sram GX Eagle DUB 32t |
| HANDLEBAR | Phoenix Race Low Rise Aluminum - 780mm (XS-LG), 800mm(XL) |
| GRIPS | Phoenix Factory Lock-On |
| STEM | Phoenix Team Enduro/Trail - 35mm(XS), 45mm(SM), 55mm(MD-XL) |
| SEATPOST | SDG Tellis 105-125mm (XS), SDG Tellis 130-150mm (SM), SDG Tellis 150-170mm (MD), SDG Tellis 180-200mm (LG), SDG Tellis 210-230mm (XL) |
| SADDLE | Phoenix WTB Volt Race (Medium Width) |
| WHEELS | DT Swiss M1900 w/ DT Swiss 370 hub, 30mm - 29" 15x110 F/12x157 R |
| TIRES | Maxxis Minion DHRII 29" x 2.4" WT, TR, 3C, EXO+, MAXXTERRA Maxxis Dissector 29" x 2.4" WT, TR, 3C, EXO, MAXXTERRA |
| ROTOR | Sram Centerline 6-bolt - 180mm Sram Centerline 6-bolt - 180mm |
| CHAIN | Sram GX Eagle Flattop 12-Speed |
