Description:
Dual-Idler, Dual-Chain
Experience smooth, friction-free riding with our innovative dual-chain design! Reduce resistance, increase clearance, and improve chain retention all in one.
Comfort Within Reach
With a reach adjust headset and the 4 frame sizes offered, riders can fine tune their reach from 430mm–525mm in 5–10mm increments.
Flip It Good
Adjust your ride using the Pivot Flip Chip, switching between 'high' for conquering technical courses and 'low' for maximum speed on descents. Utilize the Suspension Flip Chip to control the coil-over shock's progressivity and conquer even the steepest and roughest terrain.
Ready for the Rough Stuff
Featuring a mid-high pivot, six-bar dw-link suspension design and 210mm of travel, the Phoenix effortlessly conquers bumps of any size and delivers unparalleled stability on downhill rides. Its eye-catching dual-chain drive operates smoothly and quietly, enhancing efficiency and minimizing pedal kickback.
- All-new mid-high pivot DW6 linkage design
- Dual-idler pulley & dual-chain drivetrain
- Mixed-wheel setup
- Adjustable Geometry via Upper Link Mounted Flip-Chip
- Adjustable Progression via Flip-Chip Lower Shock Mount
- Injection Molded Full Downtube & Chainstay Protection
- Fork-Stop Integrated Cable Ports
- Factory Series Float X2 on Pro Builds
- RockShox Vivid on Ride Builds
- 210mm Rear Wheel Travel
- 203mm Factory Series Fox 40 on Pro Builds
- 200mm RockShox Boxxer on Ride Builds
- Continental Kryptotal DH casing tires
Specs:
| KIT | Ride GX DH |
| WHEEL SIZE | 29"/27.5" |
| FRAME | Phoenix |
| WHEEL MATERIAL | Alloy |
| REAR SHOCK | RockShox Vivid Base |
| FORK | RockShox Boxxer Base 29”, 52mm offset, Charger 3 RC - 200mm |
| HEADSET | Pivot Precision Sealed Cartridge - DH |
| REAR DER | Sram GX DH 7-Speed |
| CASSETTE | SRAM PG720 DH, 11-25t |
| SHIFTER | SRAM GX, 7-Speed |
| BRAKES | Sram Maven Bronze Stealth |
| CRANKSET | Praxis DH9-73 M30 165mm (w/ Pivot 27T Ring) |
| HANDLEBAR | Phoenix Team Low Rise Alloy - 800mm |
| GRIPS | Phoenix Factory Lock-On |
| STEM | Phoenix Team DH - 45mm |
| SEATPOST | Phoenix Race Aluminum |
| SADDLE | Phoenix WTB Ride High Tail Trail |
| WHEELS | DT Swiss F1900 w/ DT Swiss 370 hub - Mixed 20x110 F/12x157 R |
| TIRES | Continental Kryptotal-F 29" x 2.4" 3C, Super Soft, DH Casing Continental Kryptotal-R 27.5" x 2.4" Super Soft, DH Casing |
| ROTOR | Sram HS2 - 220mm Sram HS2 - 200mm |
| CHAIN | SRAM PC1110, 11-Speed |
